Model # | WB FR-RDW 860 16X16 |
---|---|
Series | WB FR-RDW 860 |
Door Size (WxH) | 16" x 16" |
Rough Opening (WxH) | 16 3/8" x 16 3/8" |
Number of Latches | 1 |
Shipping Weight | 14 lbs. |
Door | 22 Gauge Steel with 5/8" Fire-Rated Drywall Pre-installed |
Frame & Trim | 22 Gauge Steel |
Casing Bead | 1″ Wide, Perforated 22 Gauge Galvanized Drywall Flange |
Finish | Satin Coat Steel |
Latches | Self-latching Bolt |
Locks | Flush, Knurled Knob Lock with 1 Key |
Hinges | Fully-concealed Hinge |
Insulation | 2" Thick ROXUL™ Mineral Wool |
Automatic Door Closer | Spring Closer |
Interior Latch Release | Allows Opening of Door from Inside |
Fire-Rating | UL Listed "B" Label for 1-1/2 Hours (vertical installation) – This Door May Be Used in a Two Hour Fire Rated Wall Assembly |
Applications | Walls Only |
Custom Sizes | Available on Request |
